Free Bedroom Layout Planner: Drag & Drop Furniture Tool To Plan Your Design

The free bedroom layout planner allows you to quickly arrange your room’s furniture and design elements with an easy to use drag and drop interface.

How to Use the Bedroom Furniture Planner Tool

Enter the area of your room, add a bed, and then begin rearranging the items. The plan will always be to scale, so that what you see is exactly what you would receive. The functions of each component are as follows.

Choose the size of your room – To get started, enter the width and length in feet of the room you want to design. You will measure your space from wall to wall, not from baseboard to baseboard, and round the dimensions off to the nearest half foot. If your bedroom is on the ground floor, tick the box next to ground floor; that single checkbox changes what constitutes a legal escape window and is why a window may be regarded as passing or failing.

Add your furniture – The bed buttons extend across Cal King through Twin. All items are shown with their actual size, with an important note that beds are depicted according to the footprint of their frame, not just the mattress. For instance, a queen mattress measures 60 inches by 80 inches, while the frame has dimensions close to 63 inches by 83 inches. This three-inch difference can easily change what fits and what doesn’t. If you click on any bed, a hint line will display the size of the mattress it is constructed around.

The same applies to the rest: a dresser begins at 58 inches by 19 inches, since that is the size of a standard six-drawer dresser. If your dresser is of different dimensions, then move the blue corner to alter its size.

Rotate the item to choose the direction in which it will face – Press the rotate button (or the small arrow on the fixture), and it will turn the item specified in quarter-turns. This is important because the planner keeps track of the direction in which each piece faces, since ‘open floor space in front’ has no meaning unless it knows where the front is. If you rotate the bed, the walkway at the foot of the bed moves too.

Put the doors and windows – When you drag a door or a window near a wall, they snap to that wall. Rotating them causes them to cycle around the room. If you select a hinged door, you get two additional controls: you can flip the hinge and choose whether it swings in or out. The dashed arc shows the part of the floor that the door occupies, and if anything is in that area, both halves of the door will light up.

Closets have their own buttons –  For example, a bifold only covers half the opening, a bypass slider doesn’t impact the doorway, and a pocket door disappears into the wall; and each type is shown as it should operate in your room.

Examine the escape window panel – Here’s what no other bedroom planner includes. If you click on a window, you’ll see three fields: clear width, clear height, and sill height. These refer to the net clear opening, that is, the opening of the hole through which a person climbs when the sash is fully open. Not the window unit. Not the rough opening.

The display beneath the window shows whether it will meet the requirements of IRC R310, and if it doesn’t, it specifies which measurement is insufficient. The default setting is set to a standard 32 by 60 double-hung window, which gives a size of about 28 by 27 inches, that is, 5.25 square feet, and this version fails to meet the standards. The majority of windows currently in use in bedrooms do not comply. It’s better to discover this here rather than having to ask an inspector.

Read the warnings – Each issue is presented as a sentence including the actual measurement. For example, ‘The dresser has 25 inches of clear floor in front and needs 42 inches’ shows what is required. The grey text that follows each item gives the figure, so you can immediately see if you are looking at code or at a convention. The same thing is shown in the shaded areas on the plan. Green indicates that clearance is available while red means that it isn’t. You can turn off the checkbox off if the plan becomes too overwhelming and crowded.

Save it, share it, or print it – The layout is saved by your own computer’s browser and so won’t be lost if you close the tab. The Copy Share Link option puts the entire plan into a URL which you can text to a partner or send to a contractor. The Download Image feature provides you with a PNG showing the dimensions, the clearance zones and the escape window verdict. The Print / Save PDF option carries out what it claims to do.

What to Know Before You Move the Bed

Measure the aisle, not the room – A room that is 12 by 12 feet may seem like a generous size; however, with a king-sized bed in it, you only have 32 inches on either side. It’s not the room size that poses the problem; it’s the narrow strip of space left over from the furniture you select.

A dresser needs 42 inches in front of it, not 24. This is the most frequent mistake: instead of planning a walkway, people merely plan a walkway together with the drawer. A dresser drawer extends 16 to 20 inches and yet you still have to stand somewhere when it is open. A length of 24 inches enables you to walk past it, though it does not allow you to use the item.

Put the bed on the wall you see when you walk in – Not the wall which has the door in it; there’s a peculiar feeling when you go into a room and see the side of a headboard, a feeling that is difficult to describe until you have corrected the situation. The further wall generally comes out on top, and if there’s a window centered on it that is even better.

Check the door swing before you commit – A door that is 32 inches wide covers an area of about seven square feet, which is nearly the entire surface of a nightstand and all of that of a laundry basket. If the door is colliding with something, try reversing the hinge first since that will cost nothing. The next thing to do is swing the door out into the hall, and the final option is to have a pocket door, even though this involves opening up the wall.

Don’t put anything tall under the escape window – A dresser placed under the window is a classic feature but really a bad idea in a bedroom. R310 doesn’t merely call for the opening to be there; it requires it to be openable from the inside without the need for a key, a tool, or special knowledge, and having a chest of drawers in the way makes this impossible. A low bench is all right, but a six-drawer dresser, no.

The rug goes under the front two-thirds of the bed – A rug measuring 8 by 10 placed under a queen-sized bed and one measuring 9 by 12 under a king-sized bed should be started about a foot in front of the nightstands and should extend past the foot of the bed. It must be wide enough so that when you stand up, your feet will fall on the wool, since that is precisely why a bedroom rug is needed. In the planner the rug is positioned so that it is underneath all the furniture and does not obstruct any walking area since you walk on it.

Nightstand height beats nightstand width – Set it at the same height as the top of the mattress or within a couple of inches above or below that point; if it’s too low, you’ll have to reach down for your glasses in the dark. The gap between the furniture and the bed should be small, about 2 to 6 inches, so that a mug can be placed on it without having to lean. The planner regards nightstands as normal when measuring the space along the bed, rather than considering them an obstruction.

What the Clearance Check Is Based On

This tool requires two kinds of numbers, and it’s important to know the differences. Part of it is based on law, while the rest isn’t. They are taken from the International Residential Code, which most US jurisdictions accept in some form, and are referred to by section within the tool itself. Here’s how it breaks them down.

It should be noted that the minimum dimensions of 20 inches and 24 inches do not together form a legal opening by themselves; a opening of 20 inches by 24 inches amounts to 3.3 square feet, which is well below the 5.7 square feet required by the code. All four dimensions must be satisfied at the same time; the smallest openings that actually work are about 20 inches by 41 inches or 34 inches by 24 inches.

Practical Bedroom Furniture Placement Dimensions

There is no building regulation that specifies where you should place your furniture; instead, these measurements are based on practical experience in interior design and on the actual sizes of the items you’re moving. It is because of this that a layout can be approved by inspection and yet still be extremely unpleasant to live in.

Standard Bed Sizes the Planner Uses

A headboard adds an extra 2 to 4 inches at the head, and an upgrade like a bookcase headboard adds an extra 8 to 10 inches; if your bed has one, adjust it in the planner.

Enter the size of your room, select the bed that you currently have and place it up against the wall that you usually use, then change the dropdown to Minimum workable and check whether anything is still showing in red; if nothing is red when using the minimum setting, switch to Recommended and find out what you’ll be having to give up. The compromise of making things fit is often getting a smaller bed, a wall-mounted nightstand, or by moving the dresser into the closet.

The same tool exists for two other rooms. You can lay out the walk-in closet next, or plan the bathroom the same way. And if you would rather have rendering and a furniture catalog than a clearance check, there is a roundup of full 3D bedroom design software.
