What Is A Pivot Door (Design Types & Options)
Here’s our pivot door design guide, including the benefits, different types, materials, hinge options, single vs double doors, and if theyโre worth it for your home’s interior.
A pivot door, by definition, is basically a swinging door that rotates on whatโs called a spindle or a form of vertical axis. It differs from the usual hinged doors we know of and use in terms of hinge placement.
A regular hinged door has its hinges attached to the side of the door, while a pivot door has its hinge right at the top part of the door, accounting for its โpivotโ movement.
The origins of the pivot door go way back centuries ago, in ancient cities all over the world, from the historical stone pivot doors in India to the Gate of All Nations in whatโs now known as modern-day Iran.
The basic components of a pivot door are comprised of the actual door, a top pivot, a ceiling plate, a pivot system, and a floor plate.
There are basically two pivots, the top and bottom ones. Both of these hinge systems are embedded inside the actual door and are invisible on the main finished door.
These hinges can be on any location. Its placement will more or less determine the location of its vertical axis and will dictate where the door actually pivots. [toc]
Benefits of a Pivot Door?
One of the main advantages of a pivot door is how it visually differs from a regular hinged door. The door can swing inwards or outwards, depending on where the hinge is actually placed.
Itโs a different take on doors, and it looks elegant and, at times, even unexpected. It has a unique closing movement that deviates from how regular doors work.
It can be so much bigger or larger, though. They can give you some extra leeway with the height and the width.
A pivot door can be as large as you would like it to be: This gives you the freedom to come up with whatever measurements you happen to fancy.
Pivot doors can be flexible with the materials that theyโre made of. What this means is that you can fashion a door out of literally any material you could possibly think of, be it wood or glass, stone or metal and so on and so forth.
This makes your entrances look extra elegant, and you also get to rest easy in the fact that whatever the weight of the door material may be, as long as you have the proper pivot hinges and theyโre all properly installed, it should be able to support it.
Theyโre frameless: Because of the fact that the pivot hinge is mortised inside the actual door and isnโt even visible, there is never really a need for a frame in the first place.
This makes it really easy to make your door cohesive and blend in well with the rest of the dรฉcor of the space that youโre using it in. Cohesiveness is important if you really want your design to work, and pivot doors can help out a lot with that.
Theyโre hands-free: If you canโt really make a decision on whether youโd like to add door handles or latching bolts, and so on, you absolutely donโt have to.
You can do away with them because you donโt need them at all. You can easily open or close a door with nothing more than the touch of a finger or a soft nudge with your hip. This can come in handy when youโre carrying stuff around.
More than that, it helps keep things hygienic because you donโt have to keep touching things with your hands.
Door knobs, latches, and other door implements are some of the most common grounds for bacteria to breed in and thrive. Youโre removing this from the equation because pivot doors are hands-free.
Types of Pivot Doors
Pivot doors come in a wide variety of different shapes and sizes. They can be large or small, heavy or light, swing inwards or outwards, and so much more.
Another way to categorize pivot doors is for their use: residential or commercial. Residential ones are typically smaller, whereas commercial pivot doors can, at times, be floor-to-ceiling in height and can be very elegant and grand.
They can, at times, be as tall as 20 feet if the structure allows it, based on the homeownerโs preferences.
Here are the different types to be aware of:
Pivot Front Door Or Exterior Pivot Hinged Doors
If you want to make a statement right from the get-go, opting for exterior pivot doors in your homeโs entryway could do just that for you, as they look very grand and show-stopping.
The door at the entrance is the first tangible thing anyone ever sees when they step into your home, so you might as well go big with the use of exterior pivot doors.
They can be made of any material that you can think of that can be made into a door, so the design options are widely varied.
You just need to make sure, though, that since exterior pivot doors are typically exposed to the elements, you have to make them weatherproof.
This can be done by adding a few accessories to the door, such as drop seals that are draft repellant and moisture repellant for ultimate comfort as well as temperature control.
Interior Pivot Style Doors
Interior pivot doors refer to the doors that are installed and used anywhere inside the home.
This feature can be easily installed for different types of interior doors used in the bathroom, in the bedroom, in the kitchen, in the living room, as a multi-purpose room divider, along with literally any type of indoor application that you could possibly think of.
You can opt to go frameless or with frames, depending on how sturdy you want the door to look. If you are keen on getting a little bit more indoor storage, you can even equip your interior doors with some shelves on both sides for maximum utility and functionality.
Pivot Shower Doors
Having pivot shower doors installed in your bathroom at home can totally upgrade the look and make your space look like itโs been living in the future.
Your shower doors can basically swing 180 degrees in any direction, and what this means is that you can either swing them in or out or in and out simultaneously, whatever you want.
The hinge can either be attached right in the center, creating a revolving shower door effect, or it can be on one end of the door, creating a โtailโ and a โheadโ for your pivot door.
Pivot Closet Doors
Having pivot doors in the closets can be an aesthetic option to go for but might require a little bit of maneuvering to ensure that it doesn’t eat up too much space.
Most builders would keep the pivot on the tail end so that it swings outwards. It also means that the shelves inside the closet need to have a good 5-inch gap or more so that the door swings without any issues.
A major advantage to this, though, is that you can put them side by side, and it can make it really easy to organize your closets as you can see everything all in one go as opposed to traditional types of closet doors wherein your view is limited or obscured.
Pivot Pocket Door
A pivot pocket door sits on a track within a wall. It is designed to hide the doors in a nearby cavity, and the aim is to hide the door when itโs in position.
This can work with any type of door, material, and size. They save valuable floor space because youโre making the door slide into the wall instead of creeping up into the floor.
Materials for Doors with Pivot Systems
The beauty of opting for these doors is that they can be in any type of conceivable material possible for as long as they can be fashioned into a door.
So, this opens up a lot of your choices in terms of the door materials that you would like to go for. Here are some of the most common door materials you can opt for so far.
Wood
Pivot doors that are made out of wood provide great insulation for the home because of how solid the material is. They can be made out of a wide range of wood types, from hardwoods to softwoods.
The popular wood types are oak, mahogany, teak, and so on. The type of wood used is usually dictated by what your budget, texture, and appearance preferences are for the doorโs surface and overall look and feel.
Wooden pivot doors can be used both indoors and outdoors. Itโs important to get the door sealed properly as well as put heat and water insulation in place to make sure that its lifespan is extended.
They provide character and a natural warm undertone to the space and are known to be very durable.
Glass
Glass pivot doors are usually a combination of 2 materials: glass and aluminum.
The aluminum usually makes up the door frame, whereas the rest of the door surface is made out of glass that has been inlaid. This is usually used as an outside entry door or even as a partition in some commercial areas.
The glass is usually made out of tempered glass so that in the event of earthquakes and other untoward incidents, it will just crumble up in pieces rather than break off into sharp shards, causing injuries to surrounding people.
Metal
Metal pivot doors are usually made out of double-surface steel that has been pressed together. It can be hollow on the inside, or it can be filled with materials aimed at insulation.
These doors canโt be manufactured in large sizes, though, as there are limitations to the steel plate size as well as machine suppression.
Door Pivot Options
Frameless: A frameless pivot door makes for a great and aesthetic entry door, be it in the home or in a commercial space.
Similar to most pivot doors, they rotate off of hinges located both at the top and at the bottom of the door.
The frameless ones are usually set with an overhead closer thatโs concealed, allowing the door the capacity to open and close at different positions without ever having a need for a visible frame.
Insulated: Insulated doors are usually enhanced with thermal insulation along with other weatherproof details, ensuring that you get to keep the temperature in or out, helping you save up on your utility bills.
Thereโs usually a unique polyamide thermal break system that, in turn, guarantees high thermal performance insulation. The glazing details keep temperatures at bay, making the home energy efficient.
Tinted: If you want to opt for glass doors but have issues with the kind and amount of privacy they offer to you as a homeowner, an easy solution to this is getting the door tinted.
Thankfully, you donโt have to buy ready-made tinted doors. You can opt for clear types of glass doors and decide on the tint and design that you would like to lay on them.
This is a cheaper solution, provides more fluidity with the design, and can give you more control and options on the overall look of your glass door.
UV Ray Blocking: These UV ray-blocking doors ensure that you still get to enjoy the clarity of your glass pivot doors without the harmful UV rays penetrating them.
This is particularly helpful for areas in the home that are exposed to a lot of sunlight. It also helps in preserving carpets, sofas, and other elements in the home from damage brought in by light exposure.
Glazed Glass: A glazed glass pivot door can come in handy if you want the elegance of a glass door but arenโt too fond of the fact that itโs see-through.
Glazes can come in so many designs, colors, and textures that it really all boils down to what kind of look you would like to have for your door as well as for the space that you are upgrading.
It adds special effects to the lighting, particularly in the interior area of the home, and can turn out to be both aesthetic and practical.
Pivot Hinges for Doors
There are basically 2 classifications for pivot door hinges: offset pivots and center-hung pivots.
Offset Pivots
Offset pivots, as the name suggests, have their pivot point offset from the face of the actual door surface. Theyโre used on single-acting pivoting doors and usually come in ยพโ and 1 ยฝโ dimensions.
They allow the doors to swing past the main projecting trim on the face of the doorframe. This allows the door to open up to 180 degrees.
These pivots can hold weights of up to 1500 lbs and are aesthetically pleasing as they are concealed from view.
Center Hung Pivots
Center-hung pivots can be used on single or double-acting pivot doors. Its pivoting point is smack right in the center of the door.
Its edges are usually cut with a radius edge for double-acting doors. This will allow those doors to swing both ways, in whatever direction.
Thereโs hardware both on the frame as well as on the actual door itself, and these need to be coordinated accordingly for the door to work properly.
Another type is the lead-lined hinge. It isnโt actually lined as the name suggests, but it is lined up in assembly as itโs comprised of multiple fastener holes on both sides of the lead implement, and they need to be โlined upโ for the door to close or open.
Single Pivot Vs Double Pivot Type Door
The only difference between a single and double pivot door is the number of panels required or included.
Single pivots only have one panel, whereas double pivots have 2 panels. Both panels can swing in either direction.
It all depends on the amount of space that the opening requires. Double-pivoting doors are usually common for entryways as they have a bit more visual impact compared to single-pivot ones.
Do Doors with Pivots Open Both Ways?
Yes, they do. This is the main beauty and advantage of revolving doors over hinged doors.
Hinged doors have limited openings, and they almost always block the view or the space one way or the other.
These doors look seamless and appear as if they are floating because you can open them either from the left or the right, depending on where you apply pressure.
Do Pivot Entrance Doors Leak?
Yes, they do if left on their own. But this is where weather sealing comes in. With the proper additional attachments, you can get these leaks underway.
Is an Entryway with a Pivot Hinge Worth It?
It all depends on what your priorities are as a homeowner. From a function and practical standpoint, they donโt really have any significant advantages.
Doors, after all, are functional in their truest essences. However, if aesthetics matter a lot to you and you want to explore something more beyond the usual, pivoting doors are definitely well worth the trouble of getting them.
The way they close and open up a space is unlike any other, and this is why theyโre quite popular in the market.
